特点：
1、适用于大规格片剂的压制，可用于制药、化工、食品、电子、特种行业等。
2、整机模块化设计，维修保养方便。
3、双层三叶轮强迫加料器，加料更均匀稳定。
4、符合GMP要求。
5、采用智能中央润滑系统，保障各润滑点得到充分润滑。
1. Suitable for pressing large size tablets,It can be used in pharmaceutical, chemical, food, electronics, special industries, etc.
2. Modular design of the whole machine,Easy maintenance.
3. Double impeller force-feeder, more uniform and stable feeding.
4. Comply with GMP requirements.
5. Intelligent central lubrication system is used to ensure that each lubrication point is fully lubricated.
ZPT27 |
冲头数目Number of stations | 27 |
产量Max Output | tablets/hour | 32400 |
主压Max main pressure | kN | 400 |
预压Max pre-pressure | kN | 100 |
片径Max tablet diameter | mm | Ф60 |
充填Max filling | mm | 60 |
片厚Max tablet thickness | mm | 20 |
转速范围Rotation speed range | r/min | 5～10 |
冲杆直径Diameter of punch | mm | Ф62 |
上冲杆长度Upper punch rod length | mm | 227 |
下冲杆长度Lower punch rod length | mm | 240 |
机器特性参数Machine characteristic parameter |
尺寸Dimension | mm | 2085×1810×2130 |
重量Weight | kg | 5800 |
工作电压Operating voltage | V | 380 |
主电机功率Main motor power | kW | 18.5 |
压缩空气风量Compressed air volume | m3/h | 600 |
压缩空气压力Compressed air pressure | bar | 6 |
环境条件Environmental conditions |
相对空气湿度(非浓缩)Relative air humidity (non-concentrated)
| 5-95% |
压片室温度Tablet chamber temperature | 5-35℃ |
操作室温度Operating room temperature | 0-25℃ |
注：表中最大产量为理论最高转速时的产量，实际生产中由于颗粒状态、片剂压力、片剂直径厚度等诸多因素会影响产量。
Note: The maximum output in the table is the output at the theoretical maximum rotation speed. In actual production, many factors such as particle state, tablet pressure, tablet diameter and thickness will affect the output.
